Tray

Stacks

Compensator pin upgrade. And extra boost springs

11mm pump

Boost controller

Snorkel

Intake

Turbo

Yup well worth the anti splatter saves so much time on clean up, Im sold. I found those bags too. They mint huge load range and usable travel. Was my first choice but price held me back. Love your build BTW, go the 2jz :D Think ill do a 4 link front with panhard bar but not parallel. Top links 70 ...

Discovered anti spatter spray recently. Lift changing

Ready for gussets and burning it all in.

Thanks for all your comments. Cant wait to drive this thing
Went for Air Lift bags.
Load of 3055 lbs each
Extended: 12.5"
Closed: 2.8"

Next panhard bar.

Parallel 4 link with panhard bar.

Redoing all my links. Didn't like the spherical rod ends or the link material. I'm going to be using schedule 80 pipe and Toyota Surf rear trailing arm rubber bushes. They have a 16mm bolt. Strong, less road noise, better fitted for the application. Also making the rear with air bags so it can kneel ...

Had a good stern talk to myself and decided to finish this thing.

Short video of how the winch disc brake works. Spring slows down winch motors. Once delay timer counts down it lock brake in place with air pressure on the back of the ram.

They RPM racegear. Not sure where to buy, got them off a fellow 4 wheeler.

Roll cage cross bar for 4 point harnesses.

Cooling system bleed valve.

4 battery kill switches, each can handle 275A each.

Weighs 9kgs. Mounted using trailer gate latch.

Ground anchor

All painted.

rebuilding the front 3 link. Using Nissan safari trailing arm bushes and schedule 80 pipe.

I used an old warn solenoid pack to make the 24v supercharger. Works mint.....but burnt out ha ha to be expected.

Next mish

Its stays clean out the back and nice and high to keep it out the soup. Could look a bit better but works for now.

Used a bit of tube to gusset the brake master cylinder bracket.

Mounted the brake cylinder, air solenoids and control wiring in an ip 56 rated box. Cut a perspex window out to keep an eye on it.
